Spring news 2014 - page 2

EV 13 G-2
For metal working
EV 13 G-2A
Robust and heavy-duty drillingmachine with a wide
scope of use
Robust and heavy-duty drillingmachine with spindle
lock (arrest)
Rated power 760 W, stable aluminium casing , silent double speed gearbox, high-quality bea-
rings for high accuracy of drilling, rotation direction switch, switch with speed control for optimum
speed setting with smooth start-up for comfortable and safe material drilling, revolutions: 1st speed
0–1 000 rpm, 2nd speed 0–3 050 rpm, max. torque 1st / 2nd speed: 44 / 15Nm, chuck span 1.5–13mm,
max. drillingø: steel 13mm, aluminium20mm, wood 45mm, clampingneck ø: 43mm, weight2.5kg.
Integral part of delivery: tooth chuck, additional handle/grip SOFTGRIP, stopbar, cardboard box Integral part of delivery: quick clamping chuck, additional handle/grip SOFTGRIP, stop bar, systainer
Rated power 760 W, stable aluminium casing, silent double speed gearbox, high-quality bea-
rings for high accuracy of drilling, rotation direction switch, switch with speed control for optimum
speed setting with smooth start-up for comfortable and safe material drilling, revolutions: 1st speed
0–1 000 rpm, 2nd speed 0–3 050 rpm, max. torque 1st / 2nd speed: 44 / 15 Nm, automatic spindle
lock, chuck span 1.5–13 mm, max. drilling ø: steel 13 mm, aluminium 20 mm, wood 45 mm, clam-
ping neck ø 43 mm, weight 2.6 kg.
EBK 30-8 E EBD 30-8 E
Short and smart straight grinder with speed control Elongated straight grinder with a greater working range
Rated power 740 W, heavy-duty engine with smooth start-up increases efficacy and productivity
of labour, multifunctional digital electronic unit guarantees safety operation of the device: start-
-up current limitation for smooth operating speed setting, current protection protects the device
from burning, smooth speed control for optimum speed setting depending on the kind of material
and type of the used tool, possibility of use of a wide range of tools with the shanks 3; 6; 6,35 and
8 mm, self-detachable brush carbons, clamping neck ø 43 mm, max. tool ø 25 mm, revolutions
13 000–31 000 rpm, weight 1.3 kg.
Integral part of delivery: clamping nut, spring collet 6mm, 2wrenches, cardboard box
Integral part of delivery: additional handle/grip SOFTGRIP, clamping nut, spring collet 6 mm, 2 wren-
ches, cardboard box
Rated power 740W, heavy-duty engine with smooth start-up ensures effective and quick work, multi-
functional digital electronic unit with a number of protective and safety features: start-up current
limitation for smooth operating speed setting, current protection protects the device from burning,
smooth speed control for optimum speed setting depending on the kind of material and type of the
used tool, restart protection, possibility of use of a wide range of tools with the shanks 3; 6; 6,35
and 8 mm, self-detachable brush carbons, clamping neck ø 43 mm, max. tool ø 25 mm, revolutions
13 000–31 000 rpm, adjustable additional grip for higher work accuracy, weight 1.5 kg.
Order. no 65 403 597
High-quality brandwrenches
Order. no 65 403 596
Order no. 65 403 588 Order no. 65 403 589
12-part set
ofwrenches
forthepriceof €28.33
GRATIS
12-part set
ofwrenches
forthepriceof €28.33
GRATIS
8-part set
ofwrenches
forthepriceof €18.08
GRATIS
12-part set
ofwrenches
forthepriceof €28.33
GRATIS
186.66
excl.VAT
133.33
excl.VAT
220.00
excl.VAT
166.66
excl.VAT
